Center Caps

[split]

BRAID center caps come in a variety of shapes and sizes to suit a large variety of BRAID wheels, all of which can be found here. Because there are so many variants, we created this page to help explain everything there is to know about a seemingly simple and straightforward subject.



BRAID Caps

When ordering BRAID wheels, you have the choice to option them with center caps, which has become much more popular in recent years. Adding BRAID center caps to your order is an additional $20 per wheel, which includes the center cap itself, and the extra machining required for the center cap to mount to the wheel.

In most cases, your wheels are able to be manufactured with a cap of your choosing, however the final cap design is ultimately determined by a myriad of factors including wheel model, size, offset, PCD and center bore.

BRAID center caps are also not interchangeable with different size or different model center caps, as each cap requires specific machining to fit. Caps can also not be mounted to wheels that have not been machined to receive them, although in most cases they can be machined by the customer to accept caps later on.

Some known specs below:

  • The Medium Tall caps are only available for bolt patterns larger than 112 and center bore no larger than 72.6. Utilizes tapped holes and screws to attach.
  • The Large Flat Caps are only available for 5x130 or higher bolt patterns and utilize tapped holes and screws to attach.
  • The Extra Large Caps are only available for 5x150 and 6x139.7 or larger bolt pattern and utilize tapped holes and screws to attach.
  • The Extra Large Flat Caps are only available for 6x130 or larger bolt pattern and utilize tapped holes and screws to attach.


Replacement Caps

Although all center caps are $20 when optioning them with wheels, replacement caps range in price from $20 to $42 in price per cap, and can be found here.


Custom Caps

Another relatively recent trend is having wheels machined for non-BRAID center caps, which is another service we provide. In this case, adding custom caps to your order is an additional $40 per wheel, and for you to supply us with the center caps you would like to use.
